Adjustment options: | Brightness, Contrast, Gamma, All EcoView functions, Colour saturation, Colour temperature/White point, Colour Mode, Colour tone, Signal input, Resolution, OSD language, Scaling, Volume |
Audio input: | USB-C, DisplayPort, HDMI |
Audio output: | 3.5 mm stereo jack |
Auto EcoView: | Yes |
Backlight: | LED |
Built-in speakers: | Yes |
Button Guide: | Yes |
Case colour: | Black, White |
Certification: | CE, CB, TCO Certified Generation 9, EPA ENERGY STAR ®, TÜV/GS, TÜV/Ergonomics (including ISO 9241-307)**, TÜV/Blue Low Light Content, TÜV/Flicker Free, EPEAT 2018 (US), cTÜVus, TÜV/S, EAC, FCC-B, CAN ICES-3 (B), VCCI-B, CCC, RoHS, China RoHS, WEEE |
Colour palette/look-up table: | 1.06 billion colour tones / 10 Bit |
DICOM tone curve: | Yes |
Dimensions (mm): | 537,8 x 332,4 - 523,6 x 230 |
Dimensions without stand (mm): | 537,8 x 320,4 x 57,4 |
EcoView Index: | Yes |
EcoView Optimizer: | Yes |
Energy consumption/1000h [in kWh]: | 12 |
Energy efficiency class: | C |
Frequency: | USB-C: 31-68 kHz/59-61 Hz |
HDCP Decoder: | Yes |
Height adjustment range [mm]: | 191.2 |
Hole spacing: | VESA standard 100 x 100 mm |
Ideal and recommended resolution: | 1920 x 1080 (Full HD) |
Incline forward/backward: | 5° / 35° |
Input signal identification: | Yes |
Integrated power unit: | Yes |
Max. brightness (typical) [in cd/m²]: | 250 |
Max. colour space (typical): | sRGB |
Max. refresh rate (hertz): | 60 |
Max. viewing angle horizontal: | 178° |
Max. viewing angle vertical: | 178° |
Maximum Power Consumption (Watts): | 142 (at maximum brightness with all signal inputs and USB ports in use) |
No flickering thanks to hybrid controls: | Yes |
Number of colours or greyscale: | 16.7 million colours (USB-C, 8 Bit), 16.7 million colours (DisplayPort, 8 Bit), 16.7 million colours (HDMI, 8 Bit) |
OSD language: | de, en, fr, es, it, se, ja, zh |
Overdrive: | Yes |
Panel technology: | IPS |
Pivot: | 90° (clockwise and anti-clockwise) |
Pixel density (ppi): | 93 |
Pixel pitch (mm): | 0.2745 x 0.2745 |
Power consumption (typical) (Watts): | 11 |
Power management: | Yes |
Power Save Mode (Watts): | 0.5 |
Power supply: | AC 100-120 V / 200-240 V, 50/60 Hz |
Preset colour/greyscale modes: | sRGB, Paper, Movie, DICOM, 2x additional memory spaces |
Product line: | FlexScan |
RadiCS application classes : | VIII |
Resolution supported: | 1920 x 1080 (Full HD), 1680 x 1050, 1280 x 1024, 1024 x 768, 800 x 600, 720 x 400, 640 x 480 |
Response time grey-grey alternation (typical) [in ms]: | 5 |
Screen size (cm): | 60.5 |
Screen size (inches): | 23.8 |
Signal inputs: | USB-C (DisplayPort Alt Mode, HDCP 1.3), DisplayPort (HDCP 1.3), HDMI (Deep Colour, HDCP 1.4) |
Signal range amplifier (HDMI): | Yes |
Swivel: | 344° |
USB downstream ports: | 4 x type A |
USB specification: | USB 3.1 Gen 1 |
USB upstream ports: | 1 x type C (DisplayPort Alt Mode, 70 W max.) |
USB-C docking: | Yes |
Video signal: | USB-C, DisplayPort, HDMI (RGB, YUV) |
Viewable image size (width x height): | 527 x 296.5 |
Weight (kg): | 7.4 |
Weight without stand (kg): | 4.7 |
